Stainless Steel Armored Single Mode Fiber Optic Patch Cord with Anti-Rodent Protection and LSZH Flame Retardant

Nome da marca:	WNRLN
Número do modelo:	OS2-ARM-SM-003
MOQ:	10 peças
preço:	USD 1.50-12.00 / Piece
Detalhes da embalagem:	Saco PE individual com tampa contra poeira, caixa da marca WNRLN, caixa de papelão ondulado para exp
Condições de pagamento:	T/T, L/C, PayPal, Western Union

Informações pormenorizadas

Descrição do produto

Informações pormenorizadas

Lugar de origem:

Cantão, China

Certificação:

ISO 9001:2015, RoHS, CE, IEC 61300-2-4

Tipo de fibra:

Modo único OS2 (G652D / G657A1)

Tipos de conectores:

Sc, LC, FC, St

Tipo polonês:

UPC / APC

Tipo de armadura:

Tubo flexível de aço inoxidável + Kevlar

Material da jaqueta:

LSZH/PVC/TPU

Diâmetro do cabo:

3,0 mm (padrão) / 2,0 mm / 0,9 mm

Perda de inserção:

≤0,20dB típico, ≤0,30dB máximo

Perda de Devolução (UPC):

≥50dB

Perda de Retorno (APC):

≥60db

Resistência a esmagamento:

≥3000N/100mm

Resistência à tracção:

≥200N (Longo Prazo), ≥600N (Curto Prazo)

Raio de dobra:

≥30mm (Dinâmico), ≥15mm (Estático)

Temperatura operacional:

-40°C a +85°C

Classificação de fogo:

LSZH IEC 60332-1-2, OFNR UL 1666

Habilidade da fonte:

50.000 peças por mês

Destacar:

Armored Fiber Optic Patch Cord

Stainless Steel Tube Anti Rodent

SC LC FC ST Armored Connector

Descrição do produto

Stainless Steel Armored Single Mode Fiber Optic Patch Cord SC LC FC ST Anti Rodent LSZH for Industrial FTTA

Stainless Steel Armored Single Mode Fiber Optic Patch Cord

Flexible Stainless Steel Tube | Kevlar Reinforced | Anti-Rodent | Crush Resistant | SC LC FC ST Connectors

Stainless Steel Tube Armor

Flexible stainless steel spiral tube protects the optical fiber core from crushing, impact, and rodent bites. Withstands ≥3000N/100mm crush force without signal degradation.

Anti-Rodent Protection

Metal armor provides a physical barrier against rodent and pest damage — critical for outdoor FTTA, campus, and underground installations where cable integrity is paramount.

Kevlar Reinforcement

Additional Kevlar aramid yarn layer between the armor and jacket provides exceptional tensile strength — ≥200N long-term and ≥600N short-term pull resistance.

LSZH Flame Retardant

Low Smoke Zero Halogen jacket meets IEC 60332-1-2 fire safety standards. Minimal toxic smoke emission — safe for indoor riser, plenum, and confined space deployments.

Mechanical & Environmental Performance

Crush Resistance	≥3000N / 100mm (IEC 60794-1-2-E3)
Tensile Strength (Long Term)	≥200N
Tensile Strength (Short Term)	≥600N
Dynamic Bend Radius	≥30mm
Static Bend Radius	≥15mm
Operating Temperature	-40°C to +85°C
Storage Temperature	-45°C to +85°C
Fire Rating	LSZH (IEC 60332-1-2), OFNR (UL 1666)

Armor Construction — 3-Layer Protection

Inner Layer

0.9mm tight-buffered optical fiber with G652D/G657A1 core and 125μm cladding

Armor Layer

Flexible stainless steel spiral tube + Kevlar aramid yarn for crush and rodent resistance

Outer Jacket

LSZH/PVC/TPU outer jacket — flame retardant, UV resistant, available in 0.9/2.0/3.0mm

Harsh Environment Applications

FTTA — Fiber to the Antenna

Outdoor base station RRU to BBU connections. Armor eliminates need for protection conduit. TPU jacket for UV and weathering resistance.

Industrial & Factory Floor

Machine-to-machine fiber links in high-traffic areas with risk of crushing, abrasion, and accidental impact.

Live Broadcast & Events

Rapid deployment over floors, through doorways, and around crowds. Armor protects against foot traffic, rolling carts, and cable management stress.

Underground & Campus Backbone

Direct burial and conduit-ready. Anti-rodent armor ensures long-term reliability without costly secondary conduit systems.

Industrial Grade Quality — Factory Direct

Each armored patch cord undergoes crush resistance testing, tensile pull testing, and 100% optical performance verification. Available with SC, LC, FC, and ST connectors in UPC or APC polish. Custom lengths, jacket materials, and connector combinations. Contact us for OEM/ODM inquiries and bulk wholesale pricing.

Crush Tested ≥3000N

100% OTDR Verified

ISO 9001 Factory

Custom OEM/ODM
